5557-02R2-210/39012025
Physical
| Breakaway | No |
| Circuits (maximum) | 2 |
| Color – Resin | Natural |
|
Flammability
 |
94V-0 |
| Gender | Receptacle |
| Glow-Wire Capable | No |
| Material – Resin | Nylon |
| Net Weight | 0.663/g |
| Number of Rows | 2 |
| Packaging Type | Bag |
| Panel Mount | No |
| Pitch – Mating Interface | 4.20mm |
| Pitch – Termination Interface | 4.20mm |
| Polarized to Mating Part | Yes |
| Stackable | No |
| Temperature Range – Operating | -40° to +105°C |
| Current – Maximum per Contact | 13.0A |
