25045HP-03A
Short Description:
Item Specification
Operating Voltage AC/DC 250V
Current Rating AC/DC 3A
Operating Temperature -25℃ ~ +85℃
Insulation resistance 1000㏁
Withstanding voltage No flash over and no physical damage
Contact resistance 30mΩ MAX
Durability Contact Resistance : 50mΩ MAX
Vibration 1) Contact Resistance : 50mΩ MAX 2) Discontinue : 1μsec MAX
