22012025/22013027/KK254-3
Short Description:
| Circuits (maximum) | 2 |
| Color – Resin | Natural (White) |
Flammability  |
94V-0 |
| Gender | Receptacle |
| Glow-Wire Capable | No |
| Lock to Mating Part | Yes |
| Material – Resin | Nylon |
| Net Weight | 0.255/g |
| Number of Rows | 1 |
| Packaging Type | Bag |
| Panel Mount | No |
| Pitch – Mating Interface | 2.54mm |
| Pitch – Termination Interface | 2.54mm |
| Polarized to Mating Part | Yes |
| Stackable | No |
| Temperature Range – Operating | See Product Specification |
