172160-1
Short Description:
Product Type Features
-
Rectangular Power Connector Type : Housing
-
Connector System : Wire-to-Panel, Wire-to-Wire
Configuration Features
-
Number of Positions : 6
-
Number of Rows : 2
Electrical Characteristics
-
Operating Voltage (VAC): 600
-
Operating Voltage (VDC): 600
Contact Features
-
Contact Type : Pin
Mechanical Attachment
-
Panel Mount Feature Type : Mounting Ears
-
Panel Mount Feature : With
-
Connector Mounting Type : Panel Mount
Housing Features
-
Centerline (Pitch) : 4.2 mm [ .165 in ]
-
Housing Color : Natural
-
Housing Material : Nylon 66
Usage Conditions
-
Operating Temperature Range : -20 – 105 °C [ -4 – 221 °F ]
-
UL Flammability Rating : UL 94V-0
-
Glow Wire Rating : Standard Part – Not Glow Wire
